PN16 DN250 304 Cast SS Worm Water Reuse Double Eccentric Flanged Soft Seal Butterfly Valve

PN16 DN250 304 Cast SS Worm Water Reuse Double Eccentric Flanged Soft Seal Butterfly Valve

Product Features

    PN16 DN250 Manual Flanged Double-Eccentric Soft-Seal Butterfly Valve, with a one-piece body made of CF8 cast stainless steel, The core disc has been upgraded with mirror-grade precision polishing, paired with a high-performance elastic soft-seal seat and a proven double-eccentric low-friction design. Comprehensive optimization—from flow surfaces to sealing pairs—achieves four major performance breakthroughs: low flow resistance, anti-scaling, low wear, and zero leakage. This provides a cost-effective, long-term fluid control solution for medium-pressure, high-flow applications with stringent cleanliness requirements and a tendency toward scaling

Product Advantages

    ● The sealing surface and flow-passing surface of the butterfly disc undergo multiple precision polishing processes, achieving a mirror-like surface finish and significantly reducing surface roughness. The mirror-smooth flow-passing surface substantially reduces fluid resistance, improves flow efficiency, and lowers energy consumption during medium transportation.

    ● The valve employs a high-performance, corrosion-resistant, elastic soft-seal seat that forms a high-precision sealing pair with the mirror-polished CF8 butterfly disc. Unlike the hard contact between ordinary, rough butterfly discs and seals, the mirror-polished butterfly disc features a smooth, dense surface that uniformly and flexibly conforms to the soft-seal seat when closed. This ensures an even distribution of sealing pressure, achieving bubble-level zero leakage across the entire PN16 pressure range—with no micro-leakage at low pressure and no collapse at high pressure.

    ● Based on the classic double-eccentric design principle, the valve’s opening and closing motion path is optimized through the dual-trajectory adjustment of the stem axis offset and the disc sealing surface center offset. When the valve opens, the disc first moves radially away from the seat sealing surface and then rotates synchronously with the stem; throughout the entire process, the sealing surfaces do not experience continuous scraping, thereby reducing seal wear at the structural level.

Design Standards

Product detail

Application

    Chemical and Petrochemical Industries,Power Generation, Water Treatment and Environmental Protection,Metallurgy and Shipbuilding.

About Us

Zhejiang Yugong Fluid Technology Co., Ltd. is a comprehensive high-tech enterprise integrating production and sales. The company manufactures and operates professional butterfly valves made of stainless steel, carbon steel, titanium and other materials. Founded in 2012, the company is located in Yongjiao Oubei, the "hometown of pumps and valves in China", covering an area of 4,000 square meters and has more than 80 employees. Aiming high and forging ahead, the company looks forward to working hand in hand with new partners and walking all the way!

Our Workshop

F&Q

Customer Service

1. Before signing an official contract with our customer we will help to analyze and provide professional solution based on customer project information and come out with optimum solution.
2.  Your inquiry related to our products or price will be replied in 24hrs.
3. Keep informing our customer production process and help arrange quality checking in the factory if necessary.
4.  one-year warranty toproducts.
